Potentiometer Kit, 10K (65090020) *SPECIAL ORDER ITEM*

Potentiometer Kit, 10K, with Wires (adjustment knob for speed setup limit), ML380 only (65090020)

———

*SPECIAL ORDER ITEM*
Please Allow Approx. 4 Weeks For Delivery Of This Product

———

Analog Throttle Knob Option Kit

If the Throttle Type is set to Knob, the user can throttle the engine using a 10K ohm potentiometer on resistive input 3. As long as Throttle Type is Knob, Throttle Mode will only be manual.

When the knob is at the minimum position, the engine will be throttled at Low Speed and will be ramped up to High Speed as the knob is moved from the minimum position to the maximum position. If the Resistive Input 3 reads any resistance value above 11K ohm, the engine will be ramped down to Low Speed (usually happens when the connection with the potentiometer is lost or not connected). When the knob is not at the minimum position when the engine is started (at key on), the engine runs at Low Speed and displays the message “Turn Knob to minimum position” to the user until the knob is brought down to the minimum position. This avoids the engine going to some higher speeds at startup.

MurCal is an Authorized Distributor of Enovation Controls products.
MurCal provides experienced application and product support, before and after the sale.
