C3-2 Expansion Input/Output Module (50700958)
Details
C3-2 w/Plugs: Centurion Expansion (50700958)
The C3-2 Centurion Expansion Input/Output Module is designed for systems that require additional input/output capability.
Only one C3-2 Expansion I/O can be used with each C3 System.
This module features the following additional I/O: INPUTS:
* All input options are individually software selectable. No jumpers required.
* 8 Analog Inputs: 4-20 mA or 0-5V, 12 bit hardware.
* 8 Thermocouple Inputs: Type J or K, 12 bit hardware. Open thermocouple detection: drives channel reading high (max of scale). Cold junction compensation. OUTPUTS:
* 4 Analog Outputs: 4-20 mA, 16 bit hardware. SPECIFICATIONS:
* Power Input: 10-32 VDC
* Operating Temperature: -40 to 85øC (-40 to 185øF).
* Configuration: PC-based software MConfig Pro.
* Dimensions: 6-1/8"W, 4-7/8"H, 2-1/2"D.
* 8 Thermocouple Inputs: Type J or K, 12 bit hardware. Open thermocouple detection: drives channel reading high (max of scale). Cold junction compensation. OUTPUTS:
* 4 Analog Outputs: 4-20 mA, 16 bit hardware. SPECIFICATIONS:
* Power Input: 10-32 VDC
* Operating Temperature: -40 to 85øC (-40 to 185øF).
* Configuration: PC-based software MConfig Pro.
* Dimensions: 6-1/8"W, 4-7/8"H, 2-1/2"D.
