EGIS Charging Relay (7612B)
EGIS Automatic Charging Relay Plus - Triple Battery - 12V (7612B)
Two Independent ACRs in One Device reduce installation space and time. Significantly lowers off-state current draw.
Adjustable Auxiliary Battery Priority provides variable voltage points for each relay to share engine battery energy without sacrificing ability to start.
Start/Engine Isolation and Start Assist functions are optional for each relay; allowing protection of sensitive electronics from engine starting events or the option to boost cranking effectiveness.
Features:
- Eliminates Dead Start Batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present.
- Simple & Robust Installation: Integrated sealed plug eliminates corrosion, included DT04 harness.
- Single device reduces installation time, space, cost and points of potential failure.
- Additional Low Amp Output can be used to report device status remotely.
- Bullet-proof Construction: Sealed unit, high temperature materials allow mounting anywhere.
- Integrated thermal overload shutdown protection.
- Ultra-Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA Adjustable Off-Voltage for Auxiliary Battery Priority provides ability to share start battery energy for auxiliary without risking engine starting ability.
- Start/Engine Isolation input option for ensuring sensitive electronics do not experience voltage sags and spikes from the cranking event.
- Start Assist input option to ensure maximum cranking amps available when necessary.
- 4 Year Industry Leading Warranty
Literature
MurCal is an Authorized Distributor of EGIS Mobile Electric products.
MurCal provides experienced application and product support, before and after the sale.
