EGS21P-400-24 Electric Pressure Swichgage® (05702452)
EGS21P-400-24: Electric Pressure Swichgage®; 24 VDC (05702452)
Sharper Accuracy. Higher Durability. Advanced Technology.
The EG21 Series Electric Gage and the EGS21 Series Swichgage instrument take the electric gage to new heights with proven state of the art technology and reliability.
Specifications:
- Pressure Swichgage®
- 400 psi (2.76 MPa) [27.60 bar]
- 4 VDC Systems
Features:
▼ EG Air Core movement design
▼ Technological improvements in lighting, accuracy in reading and wiring installation
▼ Assurance of highest reliability and service
▼ Environmentally sealed design
▼ Exceeds the rigid SAE J1810 standard
▼ Corrosion-resistant materials.
▼ Desirable for marine and other environmentally sensitive applications
▼ Soft, non-glare dial and pointer illumination by “cold light” LED.
The EGS21 Series Swichgage instrument has all of the features of the EG21 Series Gage plus an adjustable set point PowerHall® Effect switch output for operating alarms or equipment shutdown. The trip point is adjustable over 90% of the scale and has a set point indicator visible from the gage face. Now you can have both, the ease of electric gage installation and the reliable switching of Murphy’s famous Swichgage instrument.
Literature
MurCal is an Authorized Distributor of Murphy by Enovation products.
MurCal provides experienced application and product support, before and after the sale.
