EICS EMISSION KEY (48700030) *SPECIAL ORDER ITEM*

EICS NSMP EMISSION KEY (48700030)

———

*SPECIAL ORDER ITEM*
Please Allow Approx. 4 Weeks For Delivery Of This Product

———

Eics emission key operating instructions:

1.When power is first applied to the display, the Murphy logo appears.

2.If the Engine ECU is broadcasting a 'Wait To Start' message, this screen will be shown. Engine manufacturers typically recommend against starting the engine while this message is broadcasted from the ECU. Once the ECU stops broadcasting this message, this screen will no longer be displayed.

3.Once the engine has started, the single engine parameter appears with the engine RPM displayed. Pressing the Right Arrow Key will display the coolant temperature. The screen can be changed to other parameters by pressing Menu.


The screen may be configured to display a single engine parameter (1-up display), or four parameters at once (4-up display). Default options are provided or you may customize the display by selecting the parameters you want.

1-Up Display

Three options are available for modification of the 1-Up display.

Use Defaults – This option contains a set of engine parameters: Engine Hours, Engine RPM, System Voltage, Battery Voltage, % Engine Load at Current RPM, Coolant Temperature, and Oil Pressure.

Custom Setup – This option allows for the modification of which parameter, the number of parameters, and the order in which the parameters are being displayed.

Automatic Scan – Selecting the scan function will cause the 1-Up Display to scroll through the selected set of parameters one at a time, momentarily pausing at each.
