Gensys 2.0 Genset Controller with Integrated PLC (A53Z0)
Gensys 2.0 Genset Controller with Integrated PLC
Gensys 2.0 is an all-in-one genset control and paralleling unit with integrated PLC, designed for generator electrical panels.
Programming By Equations
The 2.0 controller is a real PLC unit where equations and sequences can be programmed directly by the user with text editor software or Easy PLC software.
Inputs / Outputs with No Limits
The number of inputs/outputs that can be added is one of the most important on the market. Extension modules (DIN rail mounting) can be added on the CAN bus. This extends a large number and a large diversity of inputs/outputs up to 128 digital inputs, 64 digital outputs, 44 analog inputs, 32 analog outputs and CANopen standard module.
Minimum Options
The Gensys 2.0 is offered with a minimum of options to fit all types of application without expensive add-on packages. The standard Gensys 2.0 unit is recommended for all types of power plant, from 1 to 32 generators.
For specific needs, the following options are available:
• Mains paralleling
• Phase shift compensation
• External start module management
Inter-Unit Isolated CANbus
The Gensys 2.0 features an isolated CANbus dedicated to inter-module communication (dead busbar management, static paralleling, kW and kVAR load sharing). CANbus technology provides high reliability communication while maintaining low wiring cost and complexity.
Features:
This “all-in-one” unit combines all necessary functions:
• Three phases mains failure
• Engine start/stop and protections
• Alternator control and protections
• Mechanical parameters display
• Electrical parameters display
• Genset synchronization
• Load sharing and kW control
• Load sharing and kVAR control
• J1939 communications
• Configurable via its front panel or via a PC with CRE Config software. It has an embedded website which is password protected
• Includes analog load sharing lines and is compatible with most of the types of analog load sharing modules
Literature:
- Gensys 2.0 Sales Bulletin
- Gensys 2.0 Quick Start Guide
- Gensys 2.0 Wiring Example for Generator on Bus
- Gensys 2.0 Wiring Example for Generator on Mains
- Technical Documentation: Ethernet Connection Instructions
MurCal is an Authorized Distributor of CRE Technology products.
MurCal provides experienced application and product support, before and after the sale.
