J1939 Bus Splitter KIT: Six Place CAN Bus Splitter with Tin Pins, plus Set of Connectors (99-0070 KIT)

J1939 Bus Splitter KIT: Six Place CAN Bus Splitter with Tin Pins, plus Set of Connectors (99-0070 KIT)

This J1939 Bus Splitter KIT combines the 99-0070 Bus Splitter with a set of Deutsch connectors, wedge locks, sockets, and sealing plugs that will facilitate your installation of the module.

The 99-0070 CAN bus splitter provides a cost effective and space efficient way of connecting multiple devices to the J1939 CAN bus. This module reduces cost by eliminating "Y" adapters and extra harnesses typically used to provide additional connections to the bus.

99-0070 Bus Splitter Module Features:

• Reduces bus harnessing

• Reduces actual and production costs

• Reduces bus connections increasing quality & durability

• Eases troubleshooting of harnesses

• Potted for a true IP67 rating

• Operating & storage temp rating -45°C to +85°C

• Two (2) DT04-3P 3-pin Deutsch Connectors

• Six (6) Nickel Plated Pins

• Two (2) W3P-J1939 Blue Wedge Locks

• One (1) DTF15-12P 12-pin Deutsch Connector

• Rugged ABS Housing

The Connector KIT Includes:

• One (1) DT06-12SA-P012: 12-pin Deutsch Connector, Plug Type A (Gray) with Keying, Enhanced Seals

• One (1) W12S-P012 DT: Deutsch Wedge Lock, DT Series, 12 Plug (Green)

• Two (2) DT06-3S-C015: Deutsch Connectors, Male Plug (Gray), 3 Position

• Two (2) W3S-1939-P012: Deutsch Wedge Locks, DT Series, Male Plug (Blue), 3 Position

• Eighteen (18) 0462-201-16141: Deutsch Contacts, 16 Gauge Female Socket, Nickel

• Eighteen (18) 114017: Deutsch Connector Sealing Plug, Plastic (White)
