OPLFC-A-300-OS Pressure Swichgage (05701054)
OPLFC-A-300-OS: Panel Mount 4.5" Pressure Swichgage; Brass bourbon tube; 0-300 psi; Oil Sealed (05701054)
The OPLFC Series pressure gage instruments are combination pressure indicating gages with adjustable low and high limit switches. Limit switches can be wired directly to electric pilot circuits to operate alarms, shutdown or the start/stop of engines and electric motors.
The OPLFC is an oil-sealed panel mount model with a low limit lockout switch.
The "A" denotes a Grade A phosphor bronze bourdon tube with a brass tip/silver brazed socket and a 1/4 NPT connection.
It features a 4-1/2 in. (114 mm) dial for easy viewing. Adjustable limit switches are accessible from the front of the gage instrument.
Limit contacts have self-cleaning motion to enhance electrical continuity.
Literature:
MurCal is an Authorized Distributor of FW Murphy products.
MurCal provides experienced application and product support, before and after the sale.
