PV1200-T: PowerView® 1200-T (78700633)
PV1200-T: PowerView® 1200-T Touch, Non-connected (78700633)
The PowerView® 1200-T offers all the features of Murphy’s popular PV780 with more power, more memory and more real estate to show vital application information on one screen.
With its faster processor, this version of the full-color display adds more connectivity with Bluetooth, Ethernet and Wi-Fi capabilities while it includes an expansive 8GB of storage. The full-featured, configurable display integrates vital engine, transmission and diagnostic information into an easy-to-read operator interface. The 12.3-inch screen, with glove touch, can be easily viewed, even in full sunlight. The display’s bonded LCD and rugged design make it a perfect solution for all types of environments and applications. Customization of the display can be accomplished quickly via graphical programming or scripting with the PowerVision Configuration Studio® software, purchased separately. This tool allows for quick creation of personalized user interfaces, custom parameters and specialized graphics for on-screen text, OEM branding and more.
Specifications:
- Computing
- Processor: Renesas® R-Car M2 with Arm® Cortex®-A15 dual-core processor @ 1.5 GHz (32-bit)
- Operating System: QNX® Realtime Operating System
- Storage: 8 GB flash memory
- RAM: 512 MB DDR3-SDRAM
- Graphics: Renesas graphics processor
- Display
- Screen Size: 12.3 inches (320 mm × 130 mm)
- Type: LVDS IPS LCD with LED backlight, 24-bit color
- Resolution: 1280 × 480
- Contrast Ratio: Typ. 800:1
- Brightness: 1000 cd/m2
- Surface: Anti-glare
- Touch Panel: Projected capacitive (PCAP) with glove touch
- Hardware
- Real Time Clock: Available with battery backup
- Connectors:
- (2) AMPSEAL 23 pin (main)
- (1) M12 5 pin (on some variants)
- (1) USB pigtail
- Video Input: (3) NTSC/PAL (single channel viewable)
- Communication
- CAN: (2) CAN 2.0B according to ISO 11898-2, J1939 and proprietary messaging
- Serial: RS-485 serial (Modbus: master or slave)
- USB: USB 2.0 full speed host
- Electrical
- Operating Voltage: 6 – 36 VDC, reverse polarity protected
- Outputs:
- (1) 500 mA switched low-side
- (1) Frequency output (2Hz – 3KHz)
- Inputs:
- (3) Analog 0 – 5 VDC, 4-20 mA, resistive, 10-bit resolution
- (5) Discrete digital, active-high
- (1) Frequency in (2Hz – 10kHz) 5V pk-pk min, 49V pk-pk max
- Environmental
- Operating Temperature: -40˚C to +70˚C (-40˚F to +158˚F)
- Storage Temperature: -40˚C to +85˚C (-40˚F to +185˚F)
- Protection: IP66 and IP67, front and back, for outdoor use
- Vibration: 3.9 Grms (10 – 350Hz), 3 axes (ISO 15003)
- Shock: ±50G in 3 axes
- EMC/EMI: SAE J1113, ISO 13766, CE per 2014/30/EU
