PVA20-A-100-A-R1 Engine Oil Pressure Gage (78700127) *SPECIAL ORDER ITEM*

(0)No Reviews yet
$192.99
SKU: PVA20-A-100-A-R1 (78700127) *SPECIAL ORDER ITEM*

Currently out of stock, but do not worry! You can still place your order. We will process and ship your item promptly once it arrives from the manufacturer. For precise availability and estimated lead times, please contact our customer support team at sales@murcal.com

Contact Our Sales Team 661-272-4700 or sales@MurCal.com

PVA20-A-100-A-R1: 2" PowerView Gage; Engine Oil Pressure; 100 psi; A20 Brushed Silver; Remote Second Gage (78700127)

———

*SPECIAL ORDER ITEM*
Please Allow Approx. 4 Weeks For Delivery Of This Product

———

R1 = Option for a second gage of identical type on the gage network. For example: If you are already using one PVA20-A-100-A, and a second oil pressure gage is needed, order a PVA20-A-100-A-R1.

The Murphy 100 PSI/700 kPa Powerview Analog Engine Oil Pressure Gage with Brushed Silver Bezel PVA20-A-100-A-R1 is designed to display easy-to-read information transmitted by the PowerView. The PVA gages communicate with the PowerView via a single RS485 twisted pair MODBUS RTU serial link. The gage can be daisy-chained using quick-connect harnesses with watertight connectors. The major feature of the PVA gages is their balance between design and functionality.

The PVA20-A-100-A-R1 also features a smooth stepper motor operation for the 270° sweep pointer, an environmentally sealed case with two Deutsch DT style connectors molded into the casing, and green LED back lighting. In addition their plastic cases incorporate a “D” shape allowing panel cutouts that eliminate gage rotation during installation. This gage can be powered by 12 or 24 VDC systems.



FEATURES:

  • 2 inch size PowerView Gage
  • Bezel Type (flat lens) (Brushed Silver)
  • Simple Installation and Wiring Design
  • Microprocessor Driven for High Accuracy
  • Display SAE J1939 Parameters Broadcast by The PowerView System
  • Cutting-Edge, Stepper Motor Technology and Robust Functionality Combined
  • For Modern Electronic Engines and Equipment Using SAE J1939 Controller Area Network
  • PVA20–A = Engine Oil Pressure Gage
  • 100=100 psi/700 kPa
  • A = A20 (Brushed Silver)
  • R1 = Option for a second gage of identical type on the gage network. For example: If you are already using one PVA20-A-100-A, and a second oil pressure gage is needed, order a PVA20-A-100-A-R1.



Literature:

  1. Sales Bulletin
  2. Installation Instructions




MurCal is an Authorized Distributor of Murphy by Enovation products.
MurCal provides experienced application and product support, before and after the sale.
