ST5DAS-G Tattletale® Annunciator (25700005)
ST5DAS-G: Dual 5-Point Selectronic® Remote Alarm Tattletale® Annunciator with Gimbal Mount included (25700005)
The ST5DAS-G is general purpose alarm suitable for a variety of applications. This compact Tattletale annunciator tells you by a flashing LED which variable malfunctioned. The audible alarm is silenced by depressing the Alarm Silence push button, but the visual signal remains in operation until the fault is corrected and the contacts are cleared.
Preprinted peel and stick nameplates for common faults are supplied with each unit.
Specifications:
Provides two separate sets of 5 alarm points in one package.
Each set of 5 points is powered separately from the other, but they share the same negative of the power source.
Primary application is on twin engine boats.
Since each set of alarm points is powered separately, if only one engine is running there is no alarm on the engine not running. • Accepts N.O. and/or N.C. contacts.
Input voltage 8-32 VAC or 8-40 VDC.
