Trombetta J1939 Temperature Sensor Module (99-0050)

Trombetta  J1939 Temperature Sensor Module (99-0050)

This module converts up to 6 RTD inputs into hexadecimal values and transmits them to the J1939 CAN bus. External wire connections allow for up to 4 Temp Sensor Modules to be addressed on a common CAN backbone to accommodate up to 24 RTD inputs.

Features

• -40° C to 210° C sensing range
• 1° C resolution
• 6 RTD inputs
• 12V or 24V operation
• Open and short circuit detection
• Meets MIL-STD-461F for EMI
• Small footprint
• Potted – protection from extreme environments
• Easy 2 point mounting / rugged ABS housing
• Customizable

Literature:

Sales Bulletin
